Project Description

Flare Left Corner Modern Fireplace

Frameless Flare Left Corner Modern Fireplace Is Available In 8 Different Sizes

Protective Screens OR Double Glass

  • Model name reflects approximate fireplace size (A)
  • Model-H means high glass, 24″ (C)

All units are certified and approved by CSA to be installed in North America,

including in the state of California Massachusetts .

IMPERIAL

MODEL NAMEABCHE
Flare-LC-100100"97" 3/1616"28"5x8
Flare-LC-8083" 1/1680"16"28"5x8
Flare-LC-7070" 8/1667" 10/1616"28"5x8
Flare-LC-6060" 10/1657" 11/1616"28"5x8
Flare-LC-5050" 13/1647" 15/1616"28"5x8
Flare-LC-4544" 2/1641" 4/1616"28"4x6
Flare-LC-3031" 2/1628" 4/1624"35" 14/164x6
Flare-LC-2523" 4/1620" 12/1624"35" 14/164x6
Flare-LC-100-H100"97" 3/1624"35" 14/165x8
Flare-LC-80-H83" 1/1680"24"35" 14/165x8
Flare-LC-70-H70" 8/1667" 10/1624"35" 14/165x8
Flare-LC-60-H60" 10/1657" 11/1624"35" 14/165x8
Flare-LC-50-H50" 13/1647" 15/1624"35" 14/165x8
Flare-LC-45-H44" 2/1641" 4/1624"35" 14/164x6

NG

Model NameBurner Type
BTU/H MaxInput Max[KW]BTU/H MinEfficiency
Flare-100H65813
19.33250080.5
Flare-80G57629
16.93100080.2
Flare-70F55583
16.32800079.9
Flare-60E52173
15.32800079.8
Flare-50D46035
13.52275079.8
Flare-45C42966
12.62200079.7
Flare-30B34782
10.21850079.4
Flare-25A30690
91750079.4
Flare-100-HH65813
19.33250080.5
Flare-80-HG57629
16.93100080.2
Flare-70-HF55583
16.32800079.9
Flare-60-HE52173
15.32800079.8
Flare-50-HD46035
13.52275079.8
Flare-45-HC42966
12.62200079.7

LPG

Model NameBurner TypeBTU/h maxBTU max [KW]BTU minEfficiency
Flare-100H51150152550076
Flare-80G4637613.62075075
Flare-70F4296612.62000079
Flare-60E42966122000080
Flare-50D4092010.31850082
Flare-45C2625777001775082
Flare-30B262577700160081
Flare-25A2489373001250077
Flare-100-HH51150152550076
Flare-80-HG4637613.62075075
Flare-70-HF4296612.62000079
Flare-60-HE42966122000080
Flare-50-HD4092010.31850082
Flare-45-HC2625777001775082

Media Options

Features

linear fireplace

Linear Design

The linear gas fireplace is designed to apper longer over the wall projecting rectangular opening. The name “linear fireplace,” is used for the fireplace, because it can be specified by linear foot. For example, Flare 3ft, Flare 4ft or Flare 8ft. When specifying and referring to a linear fireplace, it mostly refers to a rectangular shaped fireplace.

Phone application for modern fireplace

Hand-held Application

Used in conjunction with the Flare remote or wall switch, the Myfire© app makes it possible for users to control multiple fireplaces at the house or business with a hand-held Apple or Android device with colorful, intuitive graphics.

Summer kit horizontal termination

Summer Kit (SK)

The optional Summer Kit (SK) extracts heat from the chase, directing it outside rather than into your home.  The inline system of fans allows the fireplace to operate without a significant increase in room temperature and operating the kit is as simple as starting your fireplace.

Home automation for modern fireplace

Home Automation

Modern homes are hard to control. As technology advances, the number of controlled devices increases. The Flare linear modern fireplace presents a way to connect the system to a home automation process in order to control it as part of the house, and not only with a dedicated remote.

3D multirow linear burner

3D Stainless Steel Burners

Longer, 3D stainless steel, burners (V.S a pipe burner) with deeper taller flame that extends closer to the sides of the fireplace.

glass_board

High Glass Opening

Taller, 16″ or 24″, ceramic glass opening, Improved viewing angle of the flames.

Corner Fireplace

Corner and Double Corner frameless slim contemporary fireplace design with glass to glass connection.

B6R_SYMAX_04.2014_SYMAX

Touch Remote

Six button stylish remote with timer, sleep mode, flame height adjustment, programming and temperature control.

Multi Color LED Lighting Option

Optional multi color interior RGB LED lighting.Allows perfect flames view across a bed of crushed glass, illuminated by LED under lighting.

Double Glass

Optional seamless cooled Double Glass for safety without the need of safety screens.

walls

Wallswitch

Optional modern touch wall switch

Reflective Back Radiant Ceramic Panel

Optional Timer

Optional timer to turn On/Off the fireplace for commercial and residential applications. Digital or Analog options.

power vent icon

Optional Power Vent

Optional power vent system for all Flare Fireplaces models – 3×5 vent system.

Reflective Back Radiant Ceramic Panel

Power Supply

Optional 110V power adapter for day to day use.

Slim metal black trim

Optional Transition Trim

Optional slim metal transition trim to all better connection and cover between the finishing material and the fireplace

Battery backup icon

Battery Backup & Electronic Ignition

Heats without power. Designed to operate during a power outage using battery backup. Fuel  saving electronic ignition with battery back-up.
